Thông số kỹ thuật
Tốc độ cắt: 25m / phút
Định dạng đồ họa được hỗ trợ: AI, DXF, PLT
Ứng dụng: Cắt Laser
Trạng thái: Còn mới
Cutting Thickness:6mm mild steel or carbon steel, 3mm stainless steel, 2mm aluminum
CNC hay không: Có
Chế độ làm mát: Làm mát bằng nước
Control Software:CypCut
Nơi xuất xứ: An Huy, Trung Quốc (Đại lục)
Tên thương hiệu: ACCURL
Chứng nhận: CE, ISO, SGS
Product Type:Thin Metal Fiber Laser Cutting Machine
Laser Source:IPG, SPI, Nlight (optional)
Lifetime of Laser Source:100, 000 hours
Advantage of Fiber Laser Cutting Machine:low consumption, high conversion rate, cost effective
Cutting Materials:Metals
Power Supply:AC380V, 50/60Hz
Dịch vụ hậu mãi cung cấp: Kỹ sư có sẵn cho máy móc dịch vụ ở nước ngoài
1. Description of Fiber Laser Cutting Machine
Fiber Laser Cutting Machine can cut different metals, such as carbon steel/mild steel, stainless steel, alloy steel, aluminum, titanium alloy, etc. It boasts fast cutting speed and high cutting precision. Work table size 2513, 3015, 4015, 4020, 6015, 6020 can be customized.
2. Key Information of Fiber Laser Cutting Machine
Loại sản phẩm | Máy cắt Laser sợi |
Vật liệu cắt | carbon steel/mild steel, stainless steel, alloy steel, aluminum, titanium alloy |
Các ngành công nghiệp ứng dụng | shipbuilding, railway locomotives, automobile, cao pressure vessels, electric cabinets, household appliances, textile machinery, engineering machinery, High precision parts, elevators, sheet metal processing, etc.
|
Định dạng đồ họa được hỗ trợ | AI, DXF, PLT, GBX
|
Chức năng hệ thống điều khiển được hỗ trợ | kết nối cầu, bước nhảy vọt, bồi thường khía, vv |
Phần chính | Máy công cụ, Nguồn Laser sợi, Đầu cắt, Hệ thống điều khiển, Hệ thống lái xe, Hệ thống làm mát bằng nước |
Bộ phận cốt lõi & Thương hiệu & trọn đời | Bộ phận cốt lõi: Nguồn Laser Fiber Thương hiệu: IPG, Raycus (tùy chọn) Trọn đời: 100, 000 giờ |
Chế độ làm mát | Hệ thống làm mát bằng nước |
Giờ làm việc liên tục | 22 giờ |
Marking Software | Phiên bản tiếng Anh Graphic Format Supported: AI, DXF, PLT, GBX Hoạt động dễ dàng Với chức năng mạnh mẽ |
3. Feature of Fiber Laser Cutting Machine
long lifetime; excellent beam quality; precision and smooth cutting edge.
fast cutting speed. It’s three times quicker than CO2 laser cutting machine.
high conversion rate between laser and electricity. (as high as 30%); low electricity consumption.
low operation costs. It’s flexible transmission. It does not require working gas, which saves operation costs.
high stability and precision
powerful functions. It’s equipped with professional CNC cutting software, which supports AI, DXF, PLT, GBX files. It boasts below functions, including bridge connection, leapfrog, slotting compensation, etc.
High Speed; High Performance; High Efficiency; Low Gas Consumption; Low Electricity Consumption; Low Operation Costs.
4. Main Parts Introduction
Công cụ máy móc
Nguồn Laser Fiber
Đầu cắt
Hệ thống điều khiển
Hệ thống lái xe
Hệ thống làm mát bằng nước
Câu hỏi thường gặp
Q: Which metal can cut? What’s cutting thickness of 500w fiber laser cutting machine?
A: Fiber laser cutting machine can cut different metals, such as mild steel/carbon steel, stainless steel, aluninum, alloys.
As for 500w fiber laser cutting machine, it can cut max. 6mm carbon steel/mild steel, 3mm stainless steel, 2mm aluminum.
Q: What’s consumables of fiber laser cutting machine?
A: Protection lens, cutting nozzle and ceramic parts. Price is very economical.
Q: If we need to cut work piece with different height, is it available?
A: Yes, it can cut work pieces with different height. The focus length can be adjusted automatically.
Q: Can we cut both sheet metal and tube or pipe using this model?
A: This design is used for sheet metals cutting. If you need to cut tube or pipe, we will add a rotary device as per your work piece’s specifications.
Q: What’s package?
A: We have 3 layers package. For the outside, we adopt plywood case. In the middle, the machine is covered by foam, to protect the machine from shaking. For the inside layer, the machine is covered by waterproof plastic bag.
Q: What’s delivery time?
A: Generally speaking, lead time is 20 working days after receive the payment.
